The working principle of Festo cylinderhttps://heiautomation.com/product/ is to convert the pressure energy of compressed gas into mechanical energy through pneumatic transmission. The specific performance is to send compressed air or gas into the cylinder and drive the linear motion of the piston by changing the air pressurehttps://heiautomation.com/product/ inside the cylinder. The following is a detailed explanation of how it works:
1. Pneumatichttps://heiautomation.com/product/ drive : When compressed air or gas enters a chamber of the cylinder (usually called a rodless chamber or a roded chamber) through the air intake, the air pressure in that chamber rises. Since the inside of the cylinder is separated by the piston into two independent chambers, namely rodless chamber and roded chamber, changes in air pressure will produce a pressure difference between the two chambers .
2, pistonhttps://heiautomation.com/product-category/danfoss/ movement : This pressure difference acts on the piston, forming a thrust or pull, pushing the piston to move to the chamber with lower pressure. The direction in which the piston moves depends on which chamber receives air. For example, when the rodless cavity intake, the rod-chamber exhaust, the piston will move in the direction of the rod-chamber, so that the piston rod is extended; On the contrary, when there is a rod-cavity intake and a rodless cavity exhaust, the piston will move in the direction of the rodless cavity, causing the piston rod to retract to .
3, doublehttps://www.youtube.com/@%E6%9B%BE%E6%85%A7%E5%A9%B7-z6j acting and single acting : Festo cylinder has both double acting and single acting. The two chambers of the double acting cylinder can be air intake to realize the bidirectional movement of the piston; Single-acting cylinders usually have only one chamber for air intake, and the return motion of the piston depends on external forces such as spring force, diaphragm tension or gravity .
- Buffer adjustment : the front and back end covers of Festo https://studio.youtube.com/channel/UC5jh-_J8N51BACPDqMnnT6Q/videos/short?filter=%5B%5D&sort=%7B%22columnType%22%3A%22date%22%2C%22sortOrder%22%3A%22DESCENDING%22%7Dcylinder usually have a buffer adjustment function, which can slow down the speed of the piston when it moves to both ends, avoid impact and noise, and improve the stability and service life of the cylinder .
5, accurate control : By accurately controlling the inlet and exit of gas and the change of air pressure, Festohttps://heiautomation.com/ cylinder can realize the precise control of piston movement, which makes it widely used in automatic production line, packaging equipment, robot technology and other fields .
Festo cylinderhttps://www.facebook.com/profile.php?id=100087291657130 is mainly composed of cylinder block, piston, piston rod, front end cover, back end cover and seals. The cylinder block is the main part of the cylinder, which is used to hold the piston and gas; The piston is the key component in the https://heiautomation.com/product/cylinder, through its movement in the cylinder to achieve the conversion of air pressure to mechanical energy; The piston rod is used to connect the cylinder to the external load and transfer the thrust or tension of the https://heiautomation.com/about/cylinder. In addition, the cylinder is also equipped with seals and buffer devices and other accessories to ensure the sealing https://www.facebook.com/profile.php?id=100087291657130performance and stability of the cylinder .
