E+H Analog pH sensor Orbisint CPS11-1AA2ESA

Potentiometric

Standard applications in process and the environment. Long-term monitoring, processes with little change.

Very robust, heavy-duty version / high pressure, integrated potential matching, flat membrane available.

pH 0-14

Gel compact electrode with PTFE ring-diaphragm.

– all shaft lengths with temperature sensor
– advanced gel technology.
– With dirt-repellent PTFE diaphragm.

Glass / PTFE

Diameter: 12 mm (0.46 inch) shaft length: 120, 225, 360 and 425 mm
(4.68, 8.77, 14.04 and 16,57 inch)

max. 135°C (274°F)

max. 16 bar (230 psi)

optional with integrated Pt100 or Pt1000

Simple operational equipment, no certification necessary.

TOP68 connection head

IP 68

Biocompatibility validated acc. to ISO 10993-5 USP (current version).
TÜV certificate for pressure resistance 16 bar, min. triple overpressure safety.
