E+H Electromagnetic 5WBB80-AADAEBJA0AQD321AA1+AK

Electromagnetic

std_productprofile_product_usp_8093.
std_productprofile_product_field_of_application_34668_1508941419.

std_productprofile_product_benefits_8095_1576681914. std_productprofile_product_benefits_8096_1576681872. Maintenance‐free – no moving parts.
International drinking water approvals. Degree of protection IP68 (Type 6P enclosure). 2-line display with push buttons.

std_productprofile_product_benefits_34707_1508943674. std_productprofile_product_benefits_34705_1508943673. std_productprofile_product_benefits_34706_1508943673.
Device as compact or remote version. HART.

DN 25…2000
1″…78″

Liner: polyurethane; hard rubber

Volume flow

±0,5% o.r. ± 2 mm/s (±0,5% o.r. ± 0,08 in/s)

9 dm3/min to 110 000 m3/h (2.5 gal/min to 700 Mgal/day)

PN 40, Class 300, 20K

‘0 to +80 °C (+32 to +176 °F), –20 to +50 °C (–4 to +122 °F)

–40 to +60 °C (–40 to +140 °F)

DN 25 to 300 (1 to 12″): AlSi10Mg, coated
DN 25 to 2000 (1 to 78″): Carbon steel with protective varnish
Sensor connection housing (standard): AlSi10Mg, coated
Sensor connection housing (option): Polycarbonate

Powder-coated die-cast aluminum

Degree of protection: IP66/67, type 4X enclosure; IP68, type 6P enclosure

Two line display
Push buttons

4…20mA + pulse,-/status (configurable)

HART

AC 20 to 28 V
AC 85 to 250 V
AC 20 to 28 V / DC 11 to 40 V

FM
CSA

CE, C-tick, EAC marking

Certificate/Test: PED/VDS

Drinking water approval: ACS, KTW-BWGL, NSF 61, WRAS BS 6920
