E+H Micropilot FMR30B – radar sensor for basic applications FMR30B-AABAKHBMXQ0WEE3+AK

Level radar

Water & Wastewater
(e.g. basins / channels / rivers / dams / lift stations /
storm water basins / pump control)
Utility applications in all industries
Storage tanks

Bluetooth® commissioning
Operation and maintenance SmartBlue App
Heartbeat Verification

2-wire (HART, 4…20 mA)
Bluetooth® wireless technology and App
(optional)

W-Band (~80 Ghz)

Liquids: +/- 2 mm (0.08″)
Solids: +/- 4 mm (0.16″)

-40…+80°C
(-40…+176°F)

-40…+80°C
(-40…+176°F)

-1…3 bar
(-14,5…43 psi)

PVDF, PBT/PC

Thread:
G1-1/2″, NPT1-1/2″
Flange:
UNI flange 2“, 3“, 4“
UNI slip on flange 3“, 4“, 6“

30m (98.4 ft)

4…20 mA HART
Bluetooth® wireless technology

ATEX, C/US, EAC Ex, JPN Ex, KC Ex,
INMETRO Ex, NEPSI Ex, UK Ex

Overfill protection WHG

EU Food Contact Material (EC) 1935/2004
US Food Contact Material FDA CFR 21

ABS, LR, BV, DNV

NSF/ANSI 61

Display, Remote operation via SmartBlue App using
Bluetooth®
Remote HART indicator RIA15 in order
structure
Flooding protection tube
Different mounting possibilities

Process temp. <-40°C (-40°F) or > 80°C (176°F) -> FMR62B
Very aggressive media -> FMR62B
Turbulences, stilling well and bypass -> FMR62B
Strong foam and interfaces –> FMP5x
