E+H Proline Promag H 100 electromagnetic flowmeter 5H1B50-AADBAAA00000BLPLT

Electromagnetic

Specialist for hygienic applications with an ultra-compact transmitter.
Multivariable measurement of flow, temperature and conductivity.
Dedicated to demanding applications in the food and beverage as well as in life sciences industries.

Flexible installation concept – numerous hygienic process connections. Energy‐saving flow measurement – no pressure loss due to cross section constriction. Maintenance‐free – no moving parts.
Integrated temperature measurement. Sensor housing made of stainless steel (3-A, EHEDG). Wetted materials CIP, SIP cleanable.

Space‐saving transmitter – full functionality on the smallest footprint. Time‐saving local operation without additional software and hardware – integrated web server. Integrated verification – Heartbeat Technology.
Robust, ultra-compact transmitter housing. High degree of protection: IP69. Local display available.

DN 2 to 150 (¹⁄₁₂ to 6″)

Liner: PFA
Electrodes: 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022); Tantalum; Platinum
Process Connections: stainless steel, 1.4404 (F316L); PVDF; PVC adhesive sleeve
Seals: O-ring seal (EPDM, FKM, Kalrez), aseptic molded seal (EPDM, FKM, silicone)
Grounding Rings: stainless steel, 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022); tantalum

Volume flow, temperature, conductivity, mass flow, corrected volume flow, corrected
conductivity

Volume flow (standard): ±0.5 % o.r. ± 1 mm/s (0.04 in/s)
Volume flow (option) ±0.2 % o.r. ± 2 mm/s (0.08 in/s)

0.06 dm³/min to 600 m³/h (0.015 to 2650 gal/min)

PN 40, Class 150, 20K

–20 to +150 °C (–4 to +302 °F)

–40 to +60 °C (–40 to +140 °F)

1.4301 (304), corrosion resistant

Compact: AlSi10Mg, coated
Compact/ultra‐compact: 1.4301 (304)

Standard: IP66/67, type 4X enclosure
Option: IP69

4‐line backlit display available (no local operation)
Configuration via web browser and operating tools possible

4‐20 mA HART (active)
Pulse/frequency/switch output (passive)

None

HART, PROFIBUS DP, Modbus RS485, EtherNet/IP, PROFINET

DC 20 to 30 V

ATEX, IECEx, cCSAus, INMETRO, EAC

CE, C-tick

Calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025)
Heartbeat Verification: Heartbeat Technology complies with requirements for traceable verification according to ISO 9001:2008, chapter 7.6. a (TUV attestation)

LR approval, DNV approval, ABS approval, BV approval

PED, CRN

3.1 material

Sanitary approval: EHEDG, 3-A, liner and seals acc. to FDA, cGMP
