E+H Radar measurement Time-of-Flight Micropilot FMR57-AAACCABDA6RVJ1OP

Level radar solid

For highest demands in measuring tasks of bulk solids:
Reliable, non-contact level measurement in high silos, bunkers or stockpiles also under extreme conditions like strongly dusting and build-up forming media

Heartbeat Technology,
Bluetooth® commissioning,
Operation and maintenance SmartBlue App,
Safety and reliability with Multi- Echo Tracking,
HistoROM,
RFID TAG for easy identification

2-wire (HART / PROFIBUS PA/ FOUNDATION Fieldbus)
4-wire (HART),
Bluetooth® wireless technology and App (optional)

K-band (~26 GHz)

Parabolic DN200/8″, DN250/10″
Horn DN80/3″, DN100/4″

+/- 3 mm (0.12 in)

-40…+80 °C
(-40…+176 °F)

-40…+400 °C
(-40…+752 °F)

Vacuum…16 bar
(Vacuum…232 psi)

316L, PEEK, PTFE, Polyamid

Thread:
MNPT 1 1/2, R 1 1/2
Flange:
DN80…DN100,
ASME 3″…4″,
JIS 10K,
UNI DN100/8″…DN250/10″

70 m (230 ft)

4…20 mA HART
PROFIBUS PA
FOUNDATION Fieldbus
Bluetooth® wireless technology

ATEX, FM, CSA C/US, IEC Ex, INMETRO, NEPSI, KC, JPN Ex, EAC, UK Ex

SIL

EN 10204-3.1

GL/ ABS/ LR/ BV/ DNV

Display,
Customized parameterization,
Remote operation via SmartBlue App using Bluetooth®,
Antenna extension,
PWIS free

Dk < 1.6
Reduction of the max. possible measuring range through:
Media with poor reflection properties
Angle of repose
Extremely loose surfaces of bulk solids, e.g. bulk solids with low bulk weight for pneumatic filling
Build-up, above all of moist products
