FESTO Clamping cartridge KP-20-2000 178459
$1.00
+ Free Shipping- Mounting positionoptional
- Type of clamping with direction of actionon both sides Clamping via spring force, released via compressed air
- DesignTilting wedge mechanism
- VariantsPiston rod at one end
- Operating pressure0.3 MPa … 1 MPa
- Operating pressure3 bar … 10 bar
- Operating pressure43.5 psi … 145 psi
- Release pressure≥0.3 MPa
- Release pressure≥3 bar
- Round material to be clamped20 mm
- Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
- Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC2 – Moderate corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Ambient temperature-10 °C … 80 °C
- Static holding force2000 N
- Product weight170 g
- Material sealsNBR TPE-U(PU)
- Material springSpring steel
- Material housingAnodised
- Material clamp jawsBrass
- Material pistonPOM
