FESTO
FESTO Proximity sensor SMTO-8E-PS-S-LED-24 171178
$1.00
+ Free Shipping- DesignFor T-slot
- Based on standardEN 60947-5-2
- Symbol00991153
- ApprovalRCM trademark
- CE mark (see declaration of conformity)To EU EMC Directive In accordance with EU RoHS Directive
- UKCA marking (see declaration of conformity)To UK RoHS instructions
- Note on materialsRoHS-compliant
- Instructions on useSupport / actuator-sensor overview “The right sensor for the actuator”
- Measured variablePosition
- Measuring principleMagneto-resistive
- Ambient temperature-20 °C … 60 °C
- Repetition accuracy0.2 mm
- Switching outputPNP
- Switching element functionN/O contact
- Switch-on time≤1.3 ms
- Switch-off time≤7.3 ms
- Max. switching frequency130 Hz
- Max. output current100 mA
- Max. switching capacity DC2.8 W
- Voltage drop≤1.8 V
- Inductive protective circuitAdapted to MZ, MY, ME coils
- Off-state current≤0.01 mA
- Short circuit current ratingyes
- Overload protectionYes
- Operational voltage range DC10 V … 30 V
- Residual ripple10 %
- Reverse polarity protectionFor all electrical connections
- Electrical connection 1, connection typePlugs
- Electrical connection 1, connector systemM8x1, A-coded, to EN 61076-2-104
- Electrical connection 1, number of connections/cores3
- Electrical connection 1, type of mountingNot rotatable
- Electrical connection 1, compatible type of mountingCompatible with latching lock Compatible with rotatable screw-type lock
- Electrical connection 1, connection pattern00991155
- Connection outlet orientationLateral
- Material electrical contactGold-plated brass
- Material screw-type lockNickel-plated brass
- Max. tightening torque connector0.3 Nm
- Type of mountingClamped in T-slot With accessories Insertable in the slot from above
- Tightening torque1 Nm
- Mounting positionoptional
- Product weight12 g
- Housing colourBlack
- Material housingTPE-U(PU)
- Switching status indicationYellow LED
- Degree of protectionIP65 IP67
- LABS (PWIS) conformityVDMA24364-B2-L
